HELVI FOX 189 welding machine + accessories
Welding multifunctional inverter designed for MMA, TIG and MIG welding. Easy adjustment of welding parameters. Universal use.
Product code: 99820051
This product is currently out of stock. If you'd like to be notified when it becomes available again, please set up a notification.
HELVI FOX 189 welding machine + accessories
out of stock
Popis produktu
Welding multifunctional inverter designed for MMA, TIG and MIG welding. Easy adjustment of welding parameters. Universal use.
PRODUCT DESCRIPTION
- Inverter technology
- Automatic compensation against voltage drops
- Lightweight and portable
- Patented burner storage system and cable wrap
- Easy parameter setting thanks to pre-printed data
- Excellent welding results even for inexperienced users
APPS
- light industry
- agriculture
- service/maintenance
- production of steel structures
- automotive
- professional and non-professional users
INCLUDED:
- Connecting gas hose (code 30900030)
- MIG torch 15 AK - 3m - blue - EURO connection (code 23000424)
- Welding cable with electrode holder - 2 meters-16mm2 - 180AMP - 25mm2 connector (code 43210138K)
- Tubular welding wire 0,9mm - 0,5kg (code 21910116)
FEATURES:
* Note: When hovering over the image, a description of the welding function will be displayed.
TECHNICAL PARAMETERS:
| Input voltage (1-phase) | 230V - 50/60Hz | |
| Power input 60% | 2.9 KVA | |
| MMA | MIG | |
|---|---|---|
| No-load voltage Uo | 70 V | 26 V |
| Amp. min-max | 20 ÷ 180 A | 25 ÷ 180 A |
| Amp. 60974-1 |
20% 180 A |
20% 180 A 60% 105 A 100% 75 A |
| Aluminium | 0,8 ÷ 1,0 Ø mm | |
| Steel | 0,6 ÷ 0,8 Ø mm | |
| Tubular wire | 0,9 Ø mm | |
| Stainless steel | 0,8 Ø mm | |
| Soldering | 0.8 Ø mm | |
| Electrode diameter Ø | 1,6 ÷ 4,00 Ø mm | |
| Electrode type | 6013 - 7018 - CrNi | |
| Insulation | H | |
| Degree of protection | IP22S | |
| Welding machine dimensions (LxWxH) | 480x220x385 mm | |
| Package dimension (LxWxH) | 590x260x435 mm | |
| Package weight/welding machine | 12,5 / 10 Kg | |
| Ordering code | 99820051 | |
