GOTHA is Single-head cutting-off machine with upstroke blade 450 mm. Electro-welded steel basement. Gotha has 2 vertical pneumatic clamps. Cutting unit controlled by a 2,2 kW motor at 2.800 rpm with widia blade diam. 450 mm. Venturi lubrication system. Worktable with mechanical stops for quick 45°/90°/135° angle selection . Tilting angles from 10° to 170°. The machine is equipped as standard with safety and protection devices in compliance with EU regulations.
Specifications:
electro-welded steel basement
2 vertical pneumatic clamps
pivoting worktable
mechanical stops to quickly select 45°/90°/135° angles
depth adjustable back stop (linear guides)
sliding square to carry out trimmings
cutting angles from 10° to 170° with
intermediate degrees
